Specification
- Single Phase model 220-230V, 50 Hz
- Three phase model 380-415 50Hz
- All cast iron with double layer coating structure for ultimate durability
- Vortex non-clogged impeller design able to handle fluid contaminated with solid diameter up to 35 mm
- Built-in thermal protector to prevent motor burning from impeller lock
- Double side mechanical seal placed in oil bath for 24 hr operation ability also included with oilseal to protect seal face from sand or dust for sewage application
- Built-in float switch model for automatic operation
| Model | CSP-255S |
| Max. Head | 7.3 m |
| Max. Flow Rate | 190l/min |
| Weight | 20 kg |
| Power Output | 0.25kW |
| Phase | Single Phase |
| Voltage | 220V |
| Frequency | 50 Hz |
| Normal Rate (m) | 3.8 |
