Function and Characteristics :
- Air intake pressure can be adjusted freely at your request (2.5-3.5 bar), reduce coating rebound, coating savings, slim atomization amplitude, large pattern width, fine particles, perfect effect, efficient and repid spraying.
- There are various fluid nozzles available, able to match numerous kinds of air caps for your convenience.
- The spray pathway is made of stainless steel, nozzles and needles are made of S1 stainless steel, suitable for water-based paints.
Specification Product :
Weight : 503 g
Fluid Nozzle Orifice : 0.8/1.0/1.2/1.5/1.8/2.0/2.5
Air pressure : 2.5-3.0 bar (0.2-0.29 Mpa)
Air Consumption : 200-560 L/min
Pattern Width : 210-400 mm
Spray Distance : 250 mm
Coating Pressure : 0.8 bar
